Specifications
Type
Industrial Robot
Brand
Efort
Model
ER210-2700
Axes
6
Payload
210 kg
Reach
2674 mm
Repeatability
0.1 mm
Weight
1110 kg
Speed at rated payload
85 °/sec (Axis J3 at 210 kg)
IP rating
IP65 (robot body) / IP54 (control cabinet)
Mounting orientation
Floor
Controller
EC2-M (Efort Series Controller)
Power supply
3-phase AC 380V ±10%, 50/60Hz
Power consumption
8000 W
Certifications
CE, ISO (quality management system), ISO 10218-1
Safety functions
Emergency stop, safety door input, collision detection, area monitoring, safe position monitoring
Communication interfaces
Digital IO, Remote IO, fieldbus interfaces, LAN/WAN ports including Modbus TCP, Ethernet/IP, Profinet-IO, EtherCAT, CAN (optional), RS232
What are the technology applications of ER210-2700?
Primary applications of EFORT ER210-2700:Assembly, Machine Tending, Pick and place, Robot welding. But we recommend to consult with your robot supplied or the manufacturer.
What is ENCY Robot
ENCY Robot is the innovative all-in-one offline robot programming solution, speeds up complex and creative robotics tasks by multiples.
EFORT ER210-2700 applications programmed with ENCY Robot
Pick-and-Place
Welding
Frequently asked questions
Can EFORT ER210-2700 be programmed with ENCY Robot?
Yes. ENCY Robot is an equipment agnostic CAD/CAM/OLP platform which supports any known robot brand. You can use components from the equipment library or create your own with our zero-code digital twin creator software MachineMaker.
How can I start programming EFORT ER210-2700 with ENCY Robot?
Just download a fully functional trial version of ENCY Robot at the download center and start using it. You can learn how to use ENCY Robot in online training center.
It is possible to install a free version of ENCY Robot and start programming EFORT ER210-2700 with it?
Absolutely. Simply download a 30-day fully functional trial version of ENCY Robot at the download center.
How to buy ENCY Robot?
If you would like to purchase ENCY, please contact us for a quote.
