Specifications
Type
Industrial Robot
Brand
Kawasaki
Model
RA005L-A
Axes
6
Payload
5 kg
Reach
903 mm
Repeatability
0.03 mm
Weight
37 kg
IP rating
Wrist IP67; Arm IP65
Mounting orientation
Floor, Ceiling
Controller
F60
Power supply
1-phase 200-230 VAC ±10%, 50/60 Hz
Power consumption
2 kVA
Safety functions
Safety Circuit Category 4, Performance Level e (EN ISO 13849-1:2008)
Communication interfaces
USB, Ethernet, RS-232C, Digital I/O (16 inputs / 16 outputs)
What are the technology applications of RA005L-A?
Primary applications of KAWASAKI RA005L-A:Assembly, Dispensing, Machine Tending, Pick and place, Trimming. But we recommend to consult with your robot supplied or the manufacturer.
What is ENCY Robot
ENCY Robot is the innovative all-in-one offline robot programming solution, speeds up complex and creative robotics tasks by multiples.
KAWASAKI RA005L-A applications programmed with ENCY Robot
Pick-and-Place
