ABB IRB 6660 205/1.9

Heavy-Duty Industrial Robot ABB IRB 6660 205/1.9

Specifications

Type

Heavy-Duty Industrial Robot

Brand

ABB

Model

IRB 6660 205/1.9

Axes

7

Payload

205 kg

Reach

1900 mm

Repeatability

0.070 mm

Weight

1730 kg

Speed at rated payload

190 °/s

IP rating

IP67, optional FoundryPlus 2 and chip / cable protection

Operating temperature range

+5 to +50 °C (operation); −25 to +55 °C (transport/storage up to 24h); up to +70 °C short exposure

Mounting orientation

Floor

Controller

IRC5 single-cabinet

Power supply

200-600 V, 50/60 Hz

Power consumption

3600 W

Tool flange

Tool flange radius R = 87.5 mm; standard ABB IRB-6660 tool-flange interface

Certifications

CE

Safety functions

Double circuits with supervision; emergency stop; 3-position enable device; supervision to prevent overheating

Communication interfaces

Field buses for I/O; sensor interfaces; remote disk access; socket messaging

Download ABB IRB 6660 205/1.9 digital twin

Start for free
The Heavy-Duty Industrial Robot ABB IRB 6660 205/1.9 is engineered for high-performance automation, featuring seven axes and a substantial payload capacity of 205 kg. With a remarkable reach of 1900 mm and a repeatability of 0.070 mm, this robust robot operates efficiently across an array of industrial applications within temperatures ranging from +5 to +50 °C. Designed for reliability, it comes equipped with an IRC5 controller, offers an IP67 rating, and includes essential safety functions to ensure optimal operation and protection.
3D View

What are the technology applications of IRB 6660 205/1.9?

ABB IRB 6660 205/1.9 is a versatile robot suitable for a wide range of industrial applications.

Primary applications of ABB IRB 6660 205/1.9:Deburring, Machine Tending, Pick and place, Robot welding, Trimming. But we recommend to consult with your robot supplied or the manufacturer.

What is ENCY Robot

ENCY Robot is the innovative all-in-one offline robot programming solution, speeds up complex and creative robotics tasks by multiples.

Learn more about ENCY Robot ➜

A sleek interface displays a robotic arm shaping a surfboard model.

ABB IRB 6660 205/1.9 applications programmed with ENCY Robot

A robotic arm performs a pick-and-place operation with an object.

Pick-and-Place

A robotic arm performs welding on a metal plate in a work environment.

Welding

Frequently asked questions

Can ABB IRB 6660 205/1.9 be programmed with ENCY Robot?

Yes. ENCY Robot is an equipment agnostic CAD/CAM/OLP platform which supports any known robot brand. You can use components from the equipment library or create your own with our zero-code digital twin creator software MachineMaker.

Just download a fully functional trial version of ENCY Robot at the download center and start using it. You can learn how to use ENCY Robot in online training center.

Absolutely. Simply download a 30-day fully functional trial version of ENCY Robot at the download center.

If you would like to purchase ENCY, please contact us for a quote.

No. We do not sell robots and do not provide pricing information. To purchase ABB IRB 6660 205/1.9 or request a quote, please contact the manufacturer or an authorized local supplier.
