Cobot AUBO i16 Specs and Applications

Specifications

Type

Cobot

Brand

AUBO

Model

i16

Axes

Payload

16 kg

Reach

967.5 mm

Repeatability

0.1 mm

Weight

38 kg

Maximum speed

4 m/s

Speed at rated payload

3 m/s

IP rating

IP54

Mounting orientation

Any ceiling, floor, wall

Controller

AUBO-CB-M

Power supply

100-240 VAC, 50/60 Hz

Power consumption

600 W

Tool flange

ISO TS 15066 / ISO-9409-1 Compatible End-of-Arm tooling interface

Certifications

EN ISO 13849-1:2015 (PL=d, CAT3), ISO/TS 15066:2016, CE, UL, KCs, SEMI S2

Cleanroom class

ISO 14644-1 Class 5

Safety functions

10-level collision detection and sensory safety; EN ISO 13849-1:2015 (PL=d, CAT 3); ISO/TS 15066; UL, CE, KCs, SEMI S2 compliant

Communication interfaces

Ethernet, Modbus-RTU/TCP, Profinet (optional), CAN bus, supports SDK/APIs and ROS integration

The Cobot AUBO i16 is a versatile 6-axis robotic arm designed for industrial automation, capable of handling a payload of up to 16 kg with a reach of 967.5 mm. With a repeatability of 0.1 mm and a maximum speed of 4 m/s, this efficient robot is suitable for a variety of mounting orientations, including ceiling, floor, and wall. Enhanced with robust safety features, compliance to ISO standards, and multiple communication interfaces, the AUBO i16 is ideal for cleanroom applications and seamless integration into modern manufacturing processes.

3D View

What are the technology applications of i16?

AUBO i16 is a versatile robot suitable for a wide range of industrial applications.

Primary applications of AUBO i16: Assembly, Deburring, Machine Tending, Polishing. But we recommend to consult with your robot supplier or the manufacturer.
