Specifications
Type
Cobot
Brand
AUBO
Model
i3
Axes
6
Payload
3 kg
Reach
625 mm
Repeatability
0.05 mm
Weight
16 kg
Speed at rated payload
1.9 m/s
IP rating
IP54
Mounting orientation
Floor, Wall, Ceiling
Controller
AUBO-C-B-M control box with teach pendant (AUBO-TP)
Power supply
DC 48V (robot arm), AC 100-240V 50/60Hz (control box)
Power consumption
150 W
Certifications
EN ISO 13849-1:2015 PL=d CAT 3, ISO/TS 15066, ISO 10218-1:2011, EN 60204-1 + A1:2009, ISO 12100:2010, ISO 13849-1, CE, UL, KCs, SEMI S2
Cleanroom class
ISO 14644-1 Class 5
Safety functions
EN ISO 13849-1:2015 PL=d CAT 3, ISO/TS 15066 power and force limiting, 10-level collision detection, redundant safety I/O
Communication interfaces
Ethernet, Modbus RTU & TCP, CAN bus, SDK / API support for C, C++, C#, Lua, Python, ROS
What are the technology applications of i3?
Primary applications of AUBO i3:Assembly, Dispensing, Machine Tending, Pick and place, Polishing. But we recommend to consult with your robot supplied or the manufacturer.
What is ENCY Robot
ENCY Robot is the innovative all-in-one offline robot programming solution, speeds up complex and creative robotics tasks by multiples.
AUBO i3 applications programmed with ENCY Robot
Pick-and-Place
Polishing
Frequently asked questions
Can AUBO i3 be programmed with ENCY Robot?
Yes. ENCY Robot is an equipment agnostic CAD/CAM/OLP platform which supports any known robot brand. You can use components from the equipment library or create your own with our zero-code digital twin creator software MachineMaker.
How can I start programming AUBO i3 with ENCY Robot?
Just download a fully functional trial version of ENCY Robot at the download center and start using it. You can learn how to use ENCY Robot in online training center.
It is possible to install a free version of ENCY Robot and start programming AUBO i3 with it?
Absolutely. Simply download a 30-day fully functional trial version of ENCY Robot at the download center.
How to buy ENCY Robot?
If you would like to purchase ENCY, please contact us for a quote.
