Specifications
Type
Industrial Robot
Brand
Epson
Model
C4-A901SR
Axes
6
Payload
4 kg
Reach
900 mm
Repeatability
0.03 mm
Weight
29 kg
Speed at rated payload
1500 mm/s
IP rating
IP20
Operating temperature range
5 to 40 °C
Mounting orientation
Tabletop, Ceiling
Controller
RC700
Power supply
AC 200-240V, single phase
Power consumption
1.7 kVA
Tool flange
ISO 9409-1-50-4-M6
Certifications
CE Mark (EMC & Machinery Directive), RoHS Directive, UL1740, ANSI/RIA R15.06, NFPA 79
Cleanroom class
ISO 3 (ISO14644-1)
Communication interfaces
Electric: 9-pin D-Sub; Pneumatic: ø4 mm ×4; Fieldbus options: DeviceNet, Profibus, EtherNet/IP, CC-Link
What are the technology applications of C4-A901SR?
Primary applications of EPSON C4-A901SR:Assembly, Dispensing, Machine Tending, Pick and place, Trimming. But we recommend to consult with your robot supplied or the manufacturer.
