TECHMAN TM14SX

Cobot

TECHMAN6 axesDigital twin for ENCY Robot

About

The Cobot TECHMAN TM14SX is a versatile 6-axis collaborative robot designed for industrial automation applications. With a payload capacity of 14 kg and a reach of 1100 mm, it offers high precision with a repeatability of 0.03 mm, and operates at a maximum speed of 4 m/s. Ideal for various mounting orientations and equipped with advanced safety functions and communication interfaces, this robot is perfect for enhancing productivity in diverse manufacturing environments.

What are the technology applications of TM14SX?

TECHMAN TM14SX is a versatile robot suitable for a wide range of industrial applications. Primary applications of TECHMAN TM14SX: Assembly, Deburring, Machine Tending, Pick and place, Trimming. But we recommend to consult with your robot supplier or the manufacturer.

TECHMAN TM14SX applications programmed with ENCY Robot

Pick and place

What is ENCY Robot

ENCY Robot is the innovative all-in-one offline robot programming solution, speeds up complex and creative robotics tasks by multiples.

Learn more about ENCY Robot

Frequently asked questions

Yes. ENCY Robot is an equipment agnostic CAD/CAM/OLP platform which supports any known robot brand. You can use components from the equipment library or create your own with our zero-code digital twin creator software MachineMaker.

Just download a fully functional trial version of ENCY Robot at the download center and start using it. You can learn how to use ENCY Robot in online training center.

Absolutely. Simply download a 30-day fully functional trial version of ENCY Robot at the download center.

If you would like to purchase ENCY, please contact us for a quote.

No. We do not sell robots and do not provide pricing information. To purchase TECHMAN TM14SX or request a quote, please contact the manufacturer or an authorized local supplier.

Download TECHMAN TM14SX digital twin

Start for free

Specifications

General

Type: Cobot
Brand: TECHMAN
Model: TM14SX
Axes: 6

Performance

Payload: 14 kg
Reach: 1100 mm
Repeatability: 0.03 mm
Weight: 33 kg
Maximum speed: 4 m/s
Speed at rated payload: 1.1 m/s

Environment

IP rating: IP65 (robot arm), IP54 (control box and robot stick)
Mounting orientation: Floor, Wall, Ceiling
Cleanroom class: ISO Class 3

Integration

Controller: TMflow / TMflow2 (with TM Screen / Robot Stick)
Power supply: 100-240 VAC, 50/60 Hz or 22-60 VDC
Power consumption: 500 W
Tool flange: standard Techman/OMRON TM S-Series tool flange interface (compatible with OnRobot direct plug-and-play tool mounting)
Communication interfaces: RS-232, Ethernet, Modbus TCP/RTU (master & slave), optional PROFINET, optional EtherNet/IP
Safety functions: Up to 31 safety functions certified by TÜV, PL d, Cat.3 (ISO 13849-1), compliant with ISO 10218-1
Certifications: CE, UL, CSA, TÜV, ISO 10218-1, ISO 13849-1
