Cobot HANS E03-Pro Specs and Applications

Specifications

Type

Cobot

Brand

Hans

Model

E03-Pro

Axes

Payload

3 kg

Reach

590 mm

Repeatability

0.02 mm

Weight

18 kg

Maximum speed

2 m/s

Speed at rated payload

2 m/s

IP rating

IP66

Mounting orientation

Any orientation

Controller

Elfin-Pro control system with standard control box, optional mini control box, teach pendant

Power supply

100-240V AC, 50/60Hz

Power consumption

100 W

Safety functions

10 advanced security configuration functions; safety collision stop; configurable safe limits in joint, Cartesian space; monitored stop; emergency stop

Communication interfaces

TCP/IP, ModbusTCP, optional Profinet, optional Ethernet/IP

The Cobot HANS E03-Pro is a versatile 6-axis industrial robot designed for precise automation tasks with a payload capacity of 3 kg and a reach of 590 mm. With a repeatability of 0.02 mm and a maximum speed of 2 m/s, this cobot ensures high performance and accuracy in various applications. Equipped with an Elfin-Pro control system and advanced safety functions, it operates safely in any orientation while meeting IP66 standards, making it ideal for demanding industrial environments.

3D View

What are the technology applications of E03-Pro?

HANS E03-Pro is a versatile robot suitable for a wide range of industrial applications.

Primary applications of HANS E03-Pro: Deburring, Multiaxis cutting, Polishing, Robot milling, Trimming. But we recommend to consult with your robot supplier or the manufacturer.

What is ENCY Robot

ENCY Robot is the innovative all-in-one offline robot programming solution, speeds up complex and creative robotics tasks by multiples.

Learn more about ENCY Robot ➜

HANS E03-Pro applications programmed with ENCY Robot

Multiaxis cutting

Polishing

Robot milling

Frequently asked questions

Yes. ENCY Robot is an equipment agnostic CAD/CAM/OLP platform which supports any known robot brand. You can use components from the equipment library or create your own with our zero-code digital twin creator software MachineMaker.

Just download a fully functional trial version of ENCY Robot at the download center and start using it. You can learn how to use ENCY Robot in online training center.

Absolutely. Simply download a 30-day fully functional trial version of ENCY Robot at the download center.

If you would like to purchase ENCY, please contact us for a quote.

No. We do not sell robots and do not provide pricing information. To purchase HANS E03-Pro or request a quote, please contact the manufacturer or an authorized local supplier.
