Specifications
Type
Cobot
Brand
Siasun
Model
GCR16-960
Axes
6
Payload
16 kg
Reach
960 mm
Repeatability
0.03 mm
Weight
37 kg
Speed at rated payload
1.5 m/s
IP rating
IP54/IP65
Operating temperature range
-10 to 50 °C
Mounting orientation
Installed in any direction (floor, wall, ceiling)
Controller
DC00-J9
Power supply
100-240 VAC, 47-63 Hz, 10 A
Power consumption
400 W
Tool flange
GB/T 14468.1-50-4-M6 (equivalent ISO 9409-1)
Certifications
TÜV SÜD safety function certification, IEC 61508 functional safety
Safety functions
Collision detection, force and power detection, functional safety (TÜV SÜD certified, IEC 61508)
Communication interfaces
TCP/IP, Modbus/TCP, Profinet, Ethernet/IP
What are the technology applications of GCR16-960?
Primary applications of SIASUN GCR16-960:Assembly, Machine Tending, Pick and place, Robot welding. But we recommend to consult with your robot supplied or the manufacturer.
What is ENCY Robot
ENCY Robot is the innovative all-in-one offline robot programming solution, speeds up complex and creative robotics tasks by multiples.
SIASUN GCR16-960 applications programmed with ENCY Robot
Pick-and-Place
Welding
Frequently asked questions
Can SIASUN GCR16-960 be programmed with ENCY Robot?
Yes. ENCY Robot is an equipment agnostic CAD/CAM/OLP platform which supports any known robot brand. You can use components from the equipment library or create your own with our zero-code digital twin creator software MachineMaker.
How can I start programming SIASUN GCR16-960 with ENCY Robot?
Just download a fully functional trial version of ENCY Robot at the download center and start using it. You can learn how to use ENCY Robot in online training center.
It is possible to install a free version of ENCY Robot and start programming SIASUN GCR16-960 with it?
Absolutely. Simply download a 30-day fully functional trial version of ENCY Robot at the download center.
How to buy ENCY Robot?
If you would like to purchase ENCY, please contact us for a quote.
