KUKA KR 12 R850 Z400
Specifications
Type
SCARA
Brand
Kuka
Model
KR 12 R850 Z400
Axes
4
Payload
12 kg
Reach
850 mm
Repeatability
0.025 mm
Weight
51 kg
Maximum speed
2700 °/s (axis 4)
Speed at rated payload
1.1 m/s (axis 3)
IP rating
IP20 (standard version); IP54 (cleanroom version)
Mounting orientation
Floor
Controller
KR C5 micro
Power supply
AC 200-240 V, single-phase power
Power consumption
1.3 kVA
Certifications
CE
Cleanroom class
ISO 5 (for cleanroom version)
Safety functions
Meets CE requirements; ESD protection; certified for high safety in working environment
Communication interfaces
Ethernet, Field bus interfaces, digital I/O
The SCARA KUKA KR 12 R850 Z400 is a highly efficient industrial robot designed for precision tasks with its four axes and a payload capacity of 12 kg. With a reach of 850 mm and exceptional repeatability of 0.025 mm, this model achieves a maximum speed of 2700 °/s on axis 4 and operates at 1.1 m/s at its rated payload on axis 3. Ideal for both standard and cleanroom applications, the KR 12 R850 Z400 features a robust IP20 rating, with an option for IP54, and is equipped with the KR C5 micro controller, ensuring high performance and compliance with CE safety standards.
