Industrial Robot KUKA KR 30 L16 Specs and Applications

Specifications

Type

Industrial Robot

Brand

Kuka

Model

KR 30 L16

Axes

Payload

16 kg

Reach

3102 mm

Repeatability

0.070 mm

Weight

700 kg

Maximum speed

230 °/s

Speed at rated payload

230 °/s

IP rating

Manipulator IP-64; inline wrist standard IP-65; wrist “F” variant IP-67

Operating temperature

During operation: +10 °C to +55 °C; during storage/transportation: -40 °C to +60 °C

Mounting orientation

Floor, Inverted (ceiling) mounting

Controller

KR C2 edition2005 or KR C4

Power supply

400-480 VAC / 3-phase

Power consumption

14.9 kW

Tool flange

DIN/ISO 9409-1 flange for IW 16 kg (M6 screws, quality 10.9, depth of engagement min. 6 mm, max. 9 mm)

Certifications

CE; ATEX (for EX variants); conforms to directives EN 60529 (IP ratings); compliant with cleanroom standards ISO 14644-1

Cleanroom class

DIN EN ISO 14644-1, Class 4 at ≤ 40 % of maximum speed; Class 5 at ≤ 80 % of maximum speed (approx. US Federal Std. 209E class 10 and 100)

Safety functions

Mechanical axis range limitation; emergency stop (Stop 0 & Stop 1); SafeRDC on some variants

Communication interfaces

Gigabit Ethernet; external axes support via controllers; I/O via RDC-box (data junction-boxes)

The KUKA KR 30 L16 is a state-of-the-art industrial robot featuring 6 axes and a payload capacity of 16 kg, making it ideal for a variety of automation tasks. With a reach of 3102 mm and a repeatability of 0.070 mm, this robust robot offers exceptional precision and reliability. Designed for floor or inverted (ceiling) mounting, it operates efficiently within a temperature range of +10 °C to +55 °C and is equipped with advanced safety features and connectivity options, ensuring seamless integration into any industrial automation environment.

3D View

What are the technology applications of KR 30 L16?

KUKA KR 30 L16 is a versatile robot suitable for a wide range of industrial applications.

Primary applications of KUKA KR 30 L16: Assembly, Deburring, Machine Tending, Pick and place, Robot welding. But we recommend to consult with your robot supplier or the manufacturer.
